Schneider Korea Sanwa EVRPD-220NZ5MQ Motor Protector

Schneider Korea Sanwa EVRPD-220NZ5MQ Motor Protector â–  Intensive design based on MCU and ASIC â–  Various types of protection Schneider Korea Sanwa EVRPD-220NZ5MQ motor protector



Sanhe EOCR Co., Ltd. is Korea's largest manufacturer of motor protectors. The company was founded in 1981 by Dr. Jin Renxi (CEO of Schneider Electric Group Korea).

In 2001, in order to develop the company into a global, strategic enterprise, he joined the Schneider Electric Group of France.

EOCR's main products are electronic motor protection relays, electronic overcurrent relays, electronic undercurrent relays, electronic undervoltage relays, other protection and monitoring devices, and current transformers.

â–  Intensive design based on MCU and ASIC â–  Multiple types of protection â–  Wide voltage adjustment range â–  Digital voltmeter and digital settings â–  Trip cause display and easy troubleshooting â–  Manual / electric / automatic reset â–  Automatic reset time adjustable â–  Strong environmental adaptability
Schneider South Korea Sanwa EVR-FD protection
Switch name position Open "ON" Off "OFF" Reverse phase (reverse phase protection) effective Invalid Voltage imbalance effective Invalid Select reset mode automatic Artificial Automatic reset time 5 seconds (reset 5 seconds after trip) 1 second (delay 1 second after trip)
Schneider Korea Sanwa EVR-FD technical conditions
Voltage setting model range Undervoltage OVR (Continuously adjustable) Overvoltage UVR (Continuously adjustable) 220 160-240V 220-300V 440 300-440V 380-500V Delay setting Trip delay time (O-time) 0.5-10 seconds, adjustable. Missing phase 2 seconds Reverse phase 0.5 seconds Phase voltage imbalance Voltage deviation ±5% (according to O-time action) Supply voltage 220 85-250V AC 50/60HZ Optional Optional Contact form 1-SPDT(1C) capacity 3A/250V (AC) Static NO-COM is always open NC-COM normally closed Time characteristic Definite time limit Display window in working Cycle display three-phase voltage After tripping Display the cause of the action and the corresponding action voltage value Trip indication Display window 7 segment LED display Installation method 35 mm fixed / rail type
Schneider Korea Sanwa EVR-FD Typical Reference Diagram / Wiring Diagram / Installation Dimensions
